Shaft length (LTotal)
6/7 mm
Number of shafts (NShaft)
2
Shaft pitch (PShaft)
1800 µm
Shaft width (WShaft)
75 µm
Number of electrodes (NEl)
32 (2 x 16)
Electrode Pitch (PEl)
100 µm
Electrode Length (LEl)
1500 µm
Electrode size (DEl), material (EM), probe thickness (T)
Ø 25 µm Pt, 100 µm
Size of the optional, internal reference electrode
