Shaft length (LTotal)
6 mm
Number of shafts (NShaft)
4
Shaft pitch (PShaft)
200 µm
Shaft width (WShaft)
51 / 62 µm (linear-shaft, B-style-shaft)
Number of electrodes (NEl)
32 (1 x 8 linear, 3 x 8 B-style)
Electrode Pitch (PEl)
50 / 300 / 500 µm (for linear-shaft)
20 µm (x-direction, B-style-shaft)
10 / 3 µm (y-direction, B-style-shaft)
Electrode Length (LEl)
1200 / 140 µm (linear-shaft, B-style-shaft)
Electrode size (DEl), material (EM), probe thickness (T)
Ø 25 / 15 µm Pt, 100 µm
Size of the optional, internal reference electrode
