Shaft length (LTotal)
8 mm
Number of shafts (NShaft)
4
Shaft pitch (PShaft)
550 µm
Shaft width (WShaft)
80 µm
Number of electrodes (NEl)
32 (4 x 8)
Electrode Pitch (PEl)
500 µm
Electrode Length (LEl)
3500 µm
Electrode size (DEl), material (EM), probe thickness (T)
Ø 35 µm, Pt, 100 µm
Size of the optional, internal reference electrode
