Shaft length (LTotal)
5 mm
Number of shafts (NShaft)
2
Shaft pitch (PShaft)
360 µm
Shaft width (WShaft)
140 µm
Number of electrodes (NEl)
32 (2 x 16)
Electrode Pitch (PEl)
150 µm
Electrode Length (LEl)
2250 µm
Electrode size (DEl), material (EM), probe thickness (T)
35 µm, Pt, 100 µm
Size of the optional, internal reference electrode
