Shaft length (LTotal)
40 mm
Number of shafts (NShaft)
1
Shaft width (WShaft)
150 µm
Number of electrodes (NEl)
16 (8 electrodes + 3 tetrodes)
Electrode Pitch (PEl)
60 / 30 µm y-direction
Electrode Length (LEl)
570 µm
Electrode size (DEl), material (EM), probe thickness (T)
15 × 15 µm², Pt, 100 µm
Size of the optional, internal reference electrode
